| Parameter | Details |
|---|
| Input Voltage | 24VDC (18V–36V) |
| Input Current | 31.5A at 24VDC |
| Isolation Resistance | 500VDC, 30MΩ (Input-Case, Input-Output, Output-Case) |
| Input Protection | Reverse polarity and over-current (input fuse) |
| Inrush Current | <15A typical |
| Switch-On Delay | <100mSec |
| Output Voltage | 24VDC (±1%) |
| Output Current | 20.0A |
| Output Power | 480W |
| Ripple | 150mVp-p max |
| Ripple Noise | 120mVp-p max |
| Line Regulation | ≤1% of Vnom |
| Load Regulation | ≤1% of Vnom |
| Output Adjustment Range | 22 to 26VDC |
| Efficiency | >87% |
| LED Indications | DC Input (Green), DC OK (Green), DC Low/Fault (Red) |
| Cooling | Natural Convection |
| Operating Temperature | -20°C to +60°C (Derating >75°C) |
| Storage Temperature | -40°C to +100°C |
| Relative Humidity | 20%-90% RH (Non-Condensing) |
| Relay Contact | NO-contact short for OK, open for Fault |
